CrowdSafeQueueControlled ingress decision model
Know the queue
before it forms.
Preserve natural demand, hold every planned queue outside screening, meter release through ticketing, test credible failure, and connect each threshold to an operational decision.
Guided setup · no crowd-science background required
Five steps from entry assumptions to a reviewable queue concept.
Work left to right. Each change immediately updates the external queue, processing warning, spatial fit, dimensions, barrier quantity, and downloadable drawing.
Describe the entry
Who is coming here, and when does processing open?
Enter the natural demand for this entry before any proposed redirection, then identify who can accept the resulting decision.
Current model warnings (3)
- People arrive faster than the protected entry system can process them. The peak demand is 217% of capacity, so the queue grows outside security.
- The queue needs 69 m² more than the stated usable holding area. Add external space, reduce peak demand, open earlier, or add validated processing capacity.
- Ticketing would receive 103% of its capacity without control. Meter security release to 1,575 people per 15 minutes.
Replace the venue, entry demand, processing, and site dimensions before issuing a drawing. The label changes to “Edited” as soon as you change an input.
Start here
Tell us what this entry must handle
Arrival timing
When will people reach the queue?
Each bar is one 15-minute share. Use a separate controlled run when a client group has materially different timing, processing, route, or opening conditions.
Edit the 12 fifteen-minute sharesAdvanced · use when interval evidence is availableGA 5/20/75 · late-weighted
Processing
How fast can people be processed?
Hold before security. Flow after security.
Screening release is limited to what both security and ticketing can receive in the interval. Any unmet demand stays in the controlled external queue; the ticketing zone is modeled as a no-hold, flow-through area.
Generic rate guide Use only when site evidence is unavailable
Security: hand wand 150–350; walk-through detection 300–400; high-throughput screening 800–1,200 people/lane/hour.
Ticketing: hand scanned 250–400; pedestal or turnstile 500–600 people/lane/hour. Use the lower end conservatively when no local evidence exists.
External holding and set-out
Choose the space and queue to build
Processor groups can be assigned before people enter and both continuous routes remain visible to operators.
Queue switching, unbalanced allocation, processor downtime, crossflow and stopped movement in the distribution zone.
Allocate before entry, prevent queue-to-queue movement, meter each discharge separately and keep the protected cross-aisle free of holding.
Configuration rule: population and density set the net holding requirement. The generator expands one continuous queue, or uses two independently continuous queues for a dual-capable form when one would exceed 12 runs. It never creates a third queue, a holding bank, or a queue-to-queue transfer. People must be assigned before joining either queue. Turn openings, the protected cross-aisle, distribution and the assisted route are support space—not holding capacity. No ordinary queue area is assigned after screening.
Live field-plan preview
Your selected queue, dimensioned as inputs change.
The plan updates immediately when demand, space, density, run length, lane width, panel length, processing, or queue form changes.
Do not issue for installation; expand or verify the controlled external envelope.
- Two independent continuous queues are generated. Allocate people before entry; do not permit transfers or switching between queues after joining.
- The longest modeled walking path within a queue is approximately 342 m. Test walking distance, mobility, welfare, visibility, line management and emergency interfaces on the surveyed plan; 300 m is a product planning alert, not a universal standard.
Downloads use the current inputs. Update the model first, then issue the files together.
The plan is a reproducible model-derived layout concept. Before field installation, the operations team must reconcile it to a controlled survey and approve barrier openings, surface, slope, anchoring/ballast, accessible provision, sterile and emergency routes, utilities, local rules and manufacturer requirements.
Where the inputs came from
Record what you know and what still needs checking
3 material assumptions remain. Observed rates should record technology, bag policy, alarm/exception process, geometry, staffing, downtime, sample size, saturation, and event comparability.
Before the plan is issued
Complete the site review checklist
Do not issue for field installation. Expand or verify the controlled external envelope, or revise supported demand and processing assumptions.
A calculated footprint may support exploration while gates remain open. It must not be described as approved, validated, safe, or operationally ready.
Optional technical record
Need the calculations, scenarios, triggers, and methodology?
The guided workflow contains everything needed to create the queue concept. Open the technical record for review, assurance, comparison, or model handoff.
